Description
Type: Gold Touch 4K*2K HDMI 4 Ports Splitter
Color: Black
Overview:
HDMI-4K-S4 Item belongs to the HDMI signal distribution product. This is an ultra high definition HDMI
splitter supporting 3D and 4K*2K resolution. The ultra HD signal can be easily allocated to multiple monitors
that support Ultra HD signals.
The front and rear end of this product can connect to splitter, matrix and extender etc. And the picture effect
have no degradation and with good stability. When playing HD video without pause, delay and trailing as well
as perfectly supports 3D to make you enjoy three-dimensional picture.
It is widely used for video advertising, monitoring, information release, security system, multimedia teaching
system, bank, metro, computer room and long distance transmission management etc..
- Support the highest signal format: 4K*2K 30Hz, support 3D, backward compatible with 1080P
- HDMI signal bandwidth: 340MHz / 3.4Gbps
- HDMI version 1.4, HDCP 1.4
- Support EDID automatic identification
- Support Blu-ray BLU-ray DVD24 / 50 / 60fs / HD-DVD / XVYCC
- Audio format DTS-HD, Dolby-trueHD, LPCM7.1, DTS, DOLBY-AC3,DSD, HD (HBR)
- There is a signal connection indicator, and the corresponding channel has a signal output that will automatically light up
| Parameter name | Detailed description | |
| Video | protocol supported | HDCP 1.4 |
| Pixel bandwidth | 340MHz，full digital | |
| Interface bandwidth | total bandwidth 10Gbps | |
| Maximum support resolution | 4K*2K@30Hz | |
| Interface | HDMI-A | |
| Impedance | 100Ω | |
| Support | EDID | support |
| Audio format | DTS-HD/Dolby-trueHD/LPCM7.1/DTS/DOLBY-AC3/DSD/HD(HBR) | |
| HDMI input distance | 24AWG(15m) | |
| HDMI output distance | 24AWG (10m) | |
| Others | Power supply | power supply adapters：DC 5V/1A |
| Maximum power consumption | 3.8W | |
| Working temperature | -5℃ ~ +70℃ | |
| Working humidity | 5% ~ 90% | |
