8Ports VGA KVM Switch

Color: Black

SKU: KVM-VGA-8 Categories: ,
Description

Description

Type: Rack-mountable 8 Ports VGA KVM Switch
Color: Black
Overview:

The KVM-VGA-8, USB / PS/2 KVM (Keyboard, Video, Mouse) Switches are control units that allow access and
control of up to 8 computers from a single USB / PS/2 keyboard, USB / PS/2 mouse, and monitor console.

  • One console controls 8 computers
  • Be compatible with USB / PS/2 keyboard and mouse in console and PS/2, USB keyboard and mouse in computer
  • Computer selection via front panel switches and OSD
  • LEDs display for easy status monitoring
  • Auto Scan Mode for monitoring all computers
  • Superior video quality
  • Easy installation – no software required
  • Hot pluggable – add or remove computers for maintenance without powering down the switch
  • Support cross-platform operation – Windows, Linux, Mac * and Sun *
Specification:
Function8 port
ModelKVM-VGA-8
Computer ConnectionsDirect8
Cascade(Max)128
CPU Port SelectionOSD Menu, Front Panel Hot-Key, Hot-key, Remote Control IP (Optional)
ConnectorConsole ConnectorsVideo1 x VGA DB15 Female Blue
Keyboard1 x USB Type A Female, 1 x PS2 Female (Purple)
Mouse1 x USB Type A Female, 1 x PS2 Female (Green)
Computer ConnectorsVideo/Keyboard/Mouse8 x VGA DB15 Female (Blue)
Power1 x DC
IP Module Network Interface1 x RJ45
Key SwitchConnection Port Selection8 x Button
KVM Reset1 x Semi-embedded keys
IP Module Reset1 x Semi-embedded keys
IP Module Default1 x Semi-embedded keys
LEDsComputer Selection Port8 x Green
On Line8 x Red
IP Module Network Interface1 x Green, 1 x Orange
Analog ModeKeyboard, MouseUSB, PS2
Video resolution (Max)1920 x 1200 @ 60HZ Local & Remote
Scan time interval3, 5, 10, 15, 20, 30, 40, 60s (3s by default)
Operating EnvironmentOperating temperature-10˚C~50˚C
Storage temperature-20˚C~60˚C
Humidity0-80%RH, No Condensation
Physical PropertiesHousingMetal
Size432 x 155 x 44 mm
Weight1.82KG
